Standard Series, Flush Plate, 1 Gang, Weatherproof White Electric
Item Number: 31VHWP-WE
Datasheet
Close
Specifications
Design
Range of product
Standard Series
Product brand
Clipsal
Product destination
switch
Sustainable offer status
Green Premium product
Physical
Fixing mode
by screws
Marking
without marking
Mounting position
horizontal and vertical
Fixing center
84 mm
Length
115 mm
Width
73 mm
Depth
11 mm
Number of gangs
1 gang
Ip degree of protection
IP54
Reach regulation
Reference contains Substances of Very High Concern above the threshold
Eu rohs directive
Compliant with Exemptions
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Environmental disclosure
ENVPEP120506EN
Circularity profile
N/A
Material
Material
plastic
Others
Package 1 bare product quantity
1
Package 2 bare product quantity
5
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
1.1 cm
Package 1 width
7.3 cm
Package 1 length
11.5 cm
Package 1 weight
60 g
Unit type of package 2
BB1
Number of units in package 2
5
Package 2 height
11.7 cm
Package 2 width
10.2 cm
Package 2 length
13.8 cm
Package 2 weight
340 g
