Home ProductsPower Points and SwitchesImpress SeriesPush Button Switch

Impress Series, Push Button Switch, 20A, 30 Series White Electric

Item Number: 30PB-WE

White Electric 1 PCE 0
Dark Blue 1 PCE 0
Black 1 PCE 0
Red 1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	EAN	Colour
1	9311554695415	WE
10	9311554695422	WE
500	19311554695412	WE
1	9311554695392	BK
10	9311554695408	BK
500	19311554695399	BK
1	9311554718480	DB
10	9311554718497	DB
500	19311554718487	DB
1	9311554718503	RD
10	9311554718510	RD
500	19311554718500	RD

Specifications

Design

Range of product

Series 30|Impress

Product or component type

push-button

Product brand

Clipsal

Physical

Device presentation

basic element

Actuator

push-button

Local signalling

without light indicator

[ue] rated operational voltage

250 V AC

Inrush current

20 A

Depth

10 mm

Width

21 mm

Length

21 mm

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Material

Material

plastic

Others

Package 1 bare product quantity

1

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

3 cm

Package 1 width

2.8 cm

Package 1 length

7 cm

Package 1 weight

22 g

Show all specifications

Documents & downloads

hide show

All
Product Brochures
Installation Instruction
Certificates (MSDS)

ZIP

Impress - change your world with the push of a button, 25165

VERSION

1.0

DATE

29 Sep 2023

REVISION

1.0

DOWNLOAD (ZIP) 1.5 MB

ZIP

Impress Push-Button Switches & Dimmers. 2000 reasons to be impressed, 25007

VERSION

1.0

DATE

29 Sep 2023

REVISION

1.0

DOWNLOAD (ZIP) 1.6 MB

ZIP

The Revolutionary 30PB Push Button Switch, 15305

VERSION

1.0

DATE

29 Sep 2023

REVISION

1.0

DOWNLOAD (ZIP) 391 KB

ZIP

Saturn Collection. Simplicity. Beauty. Style. 26750

VERSION

3.0

DATE

02 Aug 2022

REVISION

3.0

DOWNLOAD (ZIP) 5.9 MB

ZIP

Installation Instructions - F2147 - 30/60PBBPL Bell Press Mechanism, 17705

VERSION

1.0

DATE

02 Nov 2023

REVISION

1.0

DOWNLOAD (ZIP) 181.3 KB

ZIP

Clipsal, 30PB and 60PB push button wall switches, Certificate, RCM, ULNZ LTD

VERSION

1.0

DATE

23 Feb 2024

REVISION

1.0

DOWNLOAD (ZIP) 227.3 KB

Frequently Asked Questions

hide show

Can the LED on the 30PBL switch operate without a neutral at the switch?

Yes the 30PBL can have LED indication without a neutral present. Due to having no neutral present, you can only achieve LED indicator "ON" when load is "OFF".
30PBL

Some of the key features are:

Blue LED indicator
One way/two way switching facility with loop terminal
Retrofit option in to any 30 series aperture
Suitable for fluorescent loads Up to 16AX
Shrouded in-line Terminals provide protection during installation

For further information please visit http://www.clipsal.com/Trade/Products/ProductDetail?catno=30PBL

What is the difference between 30PB and 30PBBP push button mechanisms?

30PB is a latching ON/OFF push-button switch mechanism, Impress Series, with No LED Indication, 250V 16AX/20A - 1 way / 2 way.
30PBL has led
For further information, please visit http://www.clipsal.com/Trade/Products/ProductDetail?catno=30PB
https://www.clipsal.com/products/detail?CatNo=30PBL&tab-document-1=0&itemno=30PBL-WE

30PBBP is momentary / Bell Press push-button mechanism, Impress Series, with No LED Indication, 250V 16A.
30PBBPL has LED
For further information, please visit http://www.clipsal.com/Trade/Products/ProductDetail?catno=30PBBP
https://www.clipsal.com/products/detail?CatNo=30PBBPL&tab-document-1=0&itemno=30PBBPL-WE
