Clipsal - Lighting, Batten Weatherproof LED, 36W, 1200mm, 3000K / 4000K / 6500K, IP65, IK08, white

Home ProductsLightingTPWP SeriesBatten Weatherproof LED

Clipsal - Lighting, Batten Weatherproof LED, 36W, 1200mm, 3000K / 4000K / 6500K, IP65, IK08, white

Item Number: CLITPWP1200

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

Clipsal

Product or component type

batten light

Device application

lighting

Physical

Type of installation

outdoor

[ue] rated operational voltage

230/240 V AC 50 Hz

Mounting mode

ceiling

Electrical insulation class

class II

Height

80 mm

Width

100 mm

Length

1240 mm

Net weight

1600 g

Ip degree of protection

IP65

Ik degree of protection

IK08

Relative humidity

10...95 %

Ambient air temperature for operation

-10...45 °C

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach free of svhc

Yes

Eu rohs directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental disclosure

ENVPEP2409030EN

Circularity profile

ENVEOLI2409030EN

Others

Package 1 bare product quantity

1

Package 2 bare product quantity

6

Package 3 bare product quantity

72

Packaging made with recycled cardboard

No

Packaging without single use plastic

No

Product name

TPWP Series

Operational power in w

36 W

Colour rendering index

R<sub>a</sub>=80

Luminous flux

4500 lm

Bulb lifespan

50000 h

Colour temperature

3000 K|4000 K|5700 K

Light source

LED

Shape

rectangular

Main colour tint

white

Targeted country

Australia

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

9.15 cm

Package 1 width

11.15 cm

Package 1 length

129.8 cm

Package 1 weight

2.049 kg

Unit type of package 2

CAR

Number of units in package 2

6

Package 2 height

21.6 cm

Package 2 width

37.1 cm

Package 2 length

133.3 cm

Package 2 weight

13.748 kg

Unit type of package 3

PAL

Number of units in package 3

72

Package 3 height

110 cm

Package 3 width

114 cm

Package 3 length

135 cm

Package 3 weight

187.976 kg

Halogen content performance

Halogen free plastic parts product

Halogen content performance

Halogen free plastic parts product

Take-back

No

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Carbon footprint (kg.eq.co2 per cr, total life cycle)

242.72959873173454
