Clipsal - Lighting, Circular LED, 17W, 1700lm, IP54, white

Clipsal - Lighting, Circular LED, 17W, 1700lm, IP54, white

Item Number: CLITPCLS

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

Clipsal

Product or component type

ceiling light

Device application

lighting

Market segment

residential|small commercial

Colour tint

white

Warranty

5 Years

Physical

Type of installation

indoor

[ue] rated operational voltage

230/240 V AC 50 Hz

Device mounting

ceiling

Mounting mode

surface mounted

Height

23 mm

Ip degree of protection

IP54

Ik degree of protection

IK02

Ambient air temperature for operation

0...40 °C

Relative humidity

10...95 % non-condensing

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach free of svhc

Yes

Eu rohs directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Rohs exemption information

Yes

Environmental disclosure

ENVPEP2408021EN

Circularity profile

ENVEOLI2408021EN

Material

Device composition

base white|diffuser white opal

Others

Package 1 bare product quantity

1

Package 2 bare product quantity

6

Package 3 bare product quantity

192

Operational power in w

17 W

Light source

LED

Colour rendering index

R<sub>a</sub>=80

Luminous flux

1700 lm

Bulb lifespan

50000 h

Colour temperature

3000 K|4000 K|5700 K

Beam angle

110 °

Shape

round

Diameter

294 mm

Targeted country

Australia|New Zealand

Main colour tint

white

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

30 cm

Package 1 width

2.8 cm

Package 1 length

30 cm

Package 1 weight

710 g

Unit type of package 2

CAR

Number of units in package 2

6

Package 2 height

35 cm

Package 2 width

21.3 cm

Package 2 length

34 cm

Package 2 weight

4.884 kg

Unit type of package 3

PAL

Number of units in package 3

192

Package 3 height

110 cm

Package 3 width

114 cm

Package 3 length

114 cm

Package 3 weight

170.288 kg

Halogen content performance

Halogen free plastic parts product

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Carbon footprint (kg.eq.co2 per cr, total life cycle)

14.988604716881644
