Clipsal - 56 Series, Switched Socket, Vertical 4Pin 16A Hi Cycl Grey
Item Number: 56CV416K-GY
Specifications
Design
Range
Clipsal - 56 Series
Product or component type
switched socket
Device application
power supply
Market segment
small commercial|utility|industry
Physical
[in] rated current
16 A
[ue] rated operational voltage
500 V AC 50 Hz
Protection type
without protection
Connections - terminals
screw terminal cable(s) 1.5-16 mm²
Mounting mode
surface mounted
Outlet standard
industrial
Depth
108 mm
Width
101 mm
Height
204 mm
Net weight
1.1 kg
Standards
AS/NZS 3123
Ambient air temperature for operation
-25...75 °C
Ip degree of protection
IP66 conforming to AS 60529
Eu rohs directive
Compliant with Exemptions
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Material
Material
polycarbonate: cover
Contacts material
pins: phosphor bronze
Others
Package 1 bare product quantity
1
Plug, socket category
low voltage
Outlet standard deviation
Australian/New Zealand
Plug, socket, control station shape
straight|angled
Poles description
3P + E
Targeted country
Australia
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
20.4 cm
Package 1 width
10.1 cm
Package 1 length
10.8 cm
Package 1 weight
1.1 kg
