Medilec, Single Switched Socket Module - "O" Style, 10A Double Pole - Vertical

Home ProductsHealth SolutionsMedilecSingle Switched Socket Module - "O" Style

Medilec Single Switched Socket Module - "O" Style Dark Blue

Item Number: ML/ABC15VDM-DB

Retail
N/A
RRP (Inc. GST)

Datasheet

PDF datasheet

For ML/ABC15VDM-DB

Barcode

Qty UoM EAN Colour
1 9311554673475 Dark Blue
4 9311554673482 Dark Blue
40 29311554673479 Dark Blue

Specifications

Design

Range of product

Medilec ESP Series

Product or component type

switched socket

Product brand

Clipsal

Physical

Control type

ON/OFF button

Number of gangs

1 gang

Pin number

3

Number of power socket outlets

1

Actuator

switch|rocker

Fixing mode

by screws

Local signalling

without light indicator

Mounting position

vertical

[ue] rated operational voltage

250 V AC

[in] rated current

10 A

Height

74 mm

Width

45 mm

Standards

AS/NZS 3190|AS/NZS 3003

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Rohs exemption information

Yes
Show all specifications
