Acti9, Single push button, 1NO grey

Home ProductsCircuit ProtectionActi 9Single push button

Acti9, Single push button, 1NO grey

Item Number: A9E18032

Where To Buy

Datasheet

PDF datasheet

Download

Product Dimensions

Width icon

Width18 mm

Height icon

Height82 mm

Depth icon

Depth71 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

iPB

Range

Acti9

Product or component type

push-button

Market segment

residential|small commercial

Sustainable offer status

Green Premium product

Warranty

18 months

Physical

Standards

IEC 60947-5-1|IEC 60669-1

[ie] rated operational current

20 A

[ue] rated operational voltage

250 V AC

Control type

1 push-button grey

Mounting mode

fixed

Mounting support

35 mm symmetrical DIN rail

Height

82 mm

Width

18 mm

Depth

71 mm

Electrical durability

AC-22: 30000 cycles AC 50/60 Hz

Connections - terminals

staggered tunnel terminal1 cable(s) 0.5-0.5 mm² rigid|staggered tunnel terminal1 cable(s) 0.5-0.5 mm² flexible|staggered tunnel terminal1 cable(s) 0.5-0.5 mm² flexible with ferrule|staggered tunnel terminal2 cable(s) 2.5-2.5 mm² rigid|staggered tunnel terminal2 cable(s) 2.5-2.5 mm² flexible|staggered tunnel terminal2 cable(s) 2.5-2.5 mm² flexible with ferrule

Wire stripping length

9 mm

Relative humidity

95 % at 55 °C

Ambient air temperature for operation

-35...70 °C

Ambient air temperature for storage

-40...80 °C

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach free of svhc

Yes

Eu rohs directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental disclosure

ENVPEP110301EN

Circularity profile

N/A

Others

Package 1 bare product quantity

1

Product name

Acti9 iPB

Device short name

iPB

Contacts type and composition

1 NO

Comb busbar and distribution block compatibility

upside: Clario|upside: Librio|upside: ProDis

9 mm pitches

2

Tightening torque

1 N.m

Compatibility code

iPB

Tropicalisation

2

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

2.000 cm

Package 1 width

7.500 cm

Package 1 length

9.000 cm

Package 1 weight

38.800 g

Unit type of package 2

BB1

Number of units in package 2

12

Package 2 height

8.000 cm

Package 2 width

10.000 cm

Package 2 length

23.300 cm

Package 2 weight

517.000 g

Unit type of package 3

S03

Number of units in package 3

108

Package 3 height

30.000 cm

Package 3 width

30.000 cm

Package 3 length

40.000 cm

Package 3 weight

5.074 kg

Weee

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
