Airflow Exhaust fan wall, 200mm blade dia, pull cord louvre, white

Home ProductsAir Movement & HeatingAirflowExhaust fan

Airflow Exhaust fan wall, 200mm blade dia, pull cord louvre, white

Item Number: 7108AN

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Airflow

Range

Airflow

Product brand

Clipsal

Product or component type

exhaust fan

Product destination

for wall

Sustainable offer status

Green Premium product

Warranty

3 Years

Physical

Provided equipment

fan 271 mm 271 mm 200 mm

[ue] rated operational voltage

230 V AC 50 Hz

Power consumption in w

38 W

[in] rated current

0.18 A full load

Depth

110 mm

Ip degree of protection

IPx4

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP2302013_V2

Circularity profile

N/A

Material

Material

ABS (acrylonitrile butadiene-styrene)

Others

Commercial status history

SESA65076 | Tue Sep 12 01:30:00 EDT 2023 | From Unitary Local | From 02 to 08

Package 1 bare product quantity

1

Package 2 bare product quantity

64

Main colour tint

white

Air flow

600 m3/h

Diameter

188 mm impeller:

Motor type

ball bearing

Number of blades

9

Noise level

50 dB

Fan type

axial

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

22 cm

Package 1 width

27.5 cm

Package 1 length

27.5 cm

Package 1 weight

2.912 kg

Unit type of package 2

PAL

Number of units in package 2

64

Package 2 height

109 cm

Package 2 width

113 cm

Package 2 length

113 cm

Package 2 weight

212 kg

Halogen content performance

Halogen free plastic parts product
Show all specifications
